industrial non automatic submersible pump 12V 1100 GPH

industrial submersible pumpis suitable for hydraulic systems fed with cold water—used in line to be fed by gravity or pressure. ideal For fishing Boats, Cruisers, Runabouts, Yachts, etc.

제품 번호.:
CFBP-0204-01
리드 타임:
7-30 days
제품 출처:
FUJIAN
배송 포트:
FUZHOU(MAWEI)
지불:
TT
색깔:
RED AND WHITE
MOQ:
100

문의하기

제품 세부 사항

industrial non automatic submersible pump 12V 1100 GPH

built for the harsh marine environment, are suitable to withstand the most adverse condition. The water-cooled engine ensures a long service life.
CFBP-0204-01 non automatic submersible pump 1100 GPH manual bilge pump handles the spray and rainwater that can fill a small open boat quickly. completely submersible, rust and corrosion-free and ignition protected. 12v dc submersible pumpoffers many features while keeping cost and size to a minimum.

features & benefits

* pump and switch are stand alone products

* Compact, efficient, long life motors. new mercury free float switches.

* Size: 350,500,750,1100gph in 12 and 24 volt versions.

* easy clean snap-lock strainer bases

* Anti-airlock protection

* exclusive moisture tight seals

* completely submersible

* marine grade blocked wiring

* silent and vibration-less operation.

Motor:

Compact, efficient, long life motorLeads

18 AWG,1m long leads temperature

limits

duty cycle

intermittent

Pump:

liquid temperature

110℉(43℃)Max.Max.

priming capabilities

not needed flooded suction

power

3.0 amps max current draw

max pressure

typical applications

Industry, RV&Campers, Marine, agriculture etc.

DEMENSION

standard pump configurations

model	volt	flow rate(GPH)	current rate(A)	max draw (A)	wire lead	outlet dia (Inch)	inner box
CFBP-0204-01	12	1100	3	3.5	3-PIN/1M	1-1/8”	10.2X9.2X12

performance

voltage	current	flow rate	head (M）
open	2.5	675	0
12	3.05	537	0.5
12	3.64	377	1
12	4.36	286	1.5
12	4.62	145	2
12	5	0	2.5

item	description	quantity
1	wire buckle	1
2	pump cover	1
3	tapping screw	1
4	motor bracket	1
5	motor	1
6	seal base	1
7	seal	1
8	motor cover	1
9	impeller	1
10	pump housing	1
11	strainer	1

shipping information

unit pump weight(N.W/G.W)	0.45 lbs (0.34 kg)
unit size	10 x 9 x 11.8 cm
mater carton size	52 x 38 x 26.4 cm
mater carton quantity	40pcs
mater carton weight	16kgs
